ホーム 製品光沢のラミネーションのフィルム

Gloss Lamination Film for Hot Lamination Presswork with Eva Material and Glossy Finish

Gloss Lamination Film for Hot Lamination Presswork with Eva Material and Glossy Finish

商品の詳細:
起源の場所: 中国広州
ブランド名: NEi
証明: SGS Test Report / ISO9001 / ISO14001
モデル番号: 光沢
お支払配送条件:
最小注文数量: 1 トン / トレイル注文応相談
価格: negotiable
パッケージの詳細: 12. すべてのパレットは包装ベルトでよく詰め,ストレッチフィルムでよく包まれます.
受渡し時間: 1 つの 20GP コンテナに対して 15 -20 営業日
支払条件: T/T、L/C、ウェスタンユニオン
供給の能力: 月額1000トン
連絡先
詳細製品概要
製品名:: 光沢のあるBOPPの熱ラミネーションのフィルム タイプ:: プロコーティングフィルム
原産地:: 中国広州 材料:: 12 マイクロン BOPP+ 5 マイクロン EVA
特徴:: 水分証明 硬度:: 柔らかい
応用:: プレス加工のためのラミネーション 紙コア:: 3インチ (要求に応じて提供)
表面仕上げ: 光沢 厚さ:: 17 マイクロン
ハイライト:

Gloss lamination film for hot presswork

,

EVA material lamination film

,

Glossy finish lamination film

Gloss Lamination Film for Hot Lamination Presswork with Eva Material and Glossy Finish
High Brightness Presswork Hot Lamination Roll For Mobile, Eva Lamination Film
Glossy Specifications:
TYPE THICKNESS (micron)
GLOSSY TOTAL | BASE | EVA
17 12 | 5
18 12 | 6
20 12 | 8
22 12 | 10
23 15 | 8
25 15 | 10
27 15 | 12
30 15 | 15
42 28 | 14

WIDTH (mm): 200 ~ 2210

LENGTH (m): 100 ~ 8000

PAPER CORE: 25.4mm(1 inch) / 76mm (3 inch)

BONDING: ≤2

CORONA TREATED: Double side

SURFACE TENSION: 38 Dyne/cm ≤ 42 Dyne/cm

LAMINATION TEMP.: 90±10°C

ROLLER PRESSURE: 10 ~ 20Mpa

LAMINATION SPEED: 20 ~ 70M

Description:

Thermal Lamination Films have extrusion-coated surface with low temperature melting resin, which enables the lamination of film to paper products by heat and pressure. Various surface finishes available add value to the printed surface. Glossy BOPP thermal lamination film offers a shiny colorful finish. Its use can enhance the look and increase all laminated presswork's useful lifetime.

A combination of good performance characteristics and low price point make BOPP thermal laminating films ideal for all kinds of printed & unprinted paper and paper boards, including book covers, cosmetics packaging, magazines, documents, shopping bags, Diaries etc.

Thermal lamination film is also called HOT LAMINATION FILM, HOT LAMINATING FILM, THERMAL LAMINATING FILM, and PRO-COATING FILM. 17 micron bopp thermal lamination film is widely used in Vietnam, Thailand, Indonesia, Egypt, Brazil, Mexico, Chile, Colombia, and so on.

Normal Application:
  • Documents
  • Price tags, labels
  • Shopping bags
  • Children books
  • School books
NEI BOPP thermal lamination film is widely used in the market because:
  • Environmentally friendly: non-toxic, odorless, or non-benzene because non-solvent based adhesive is used.
  • Safe operation: Non-solvent based adhesive is used so it will eliminate the fire hazard that is caused by the use and storage of flammable solvents.
  • Excellent performance: Compared with wet lamination, thermal lamination film enhances the color saturation and brightness of presswork. It also has stronger ability of absorbing powder and adhesive force. Furthermore, it is effective to prevent being blistered or separated from presswork in lamination process.
  • Easy handling: Once the required temperature and pressure is met, lamination can be easily operated. No other special technique is required.
  • High efficiency: Production cost and labor cost are reduced substantially as there is no film wastage, mixture of adhesive solvent, or no UV heating lamp (drying system) is required. Therefore, it saves production space as well.
  • Wide adaptability: It is widely adaptable to different types of lamination machines, including wet and dry laminator. Only small adjustments need to be made to the machine if wet laminator is used.
BOPP Thermal Lamination Film – Unmatched Performance for Every Application
Product Overview

Engineered for excellence, our BOPP Thermal Lamination Film is a premium protective coating crafted from Biaxially Oriented Polypropylene (BOPP). This high-performance material delivers exceptional clarity, flexibility, and resistance to moisture, chemicals, and UV rays, making it the ideal choice for enhancing the durability, aesthetics, and functionality of printed materials. Perfectly suited for laminating paper-based products such as book covers, brochures, menus, posters, and packaging materials, this film ensures long-lasting protection and visual appeal.

Key Features
  • Crystal-Clear Clarity & Gloss: Delivers a vibrant, high-gloss finish that enhances color reproduction and visual impact.
  • Superior Adhesion: Forms strong bonds with paper, cardboard, and PET films, preventing peeling or delamination.
  • High-Temperature Stability: Withstands lamination temperatures up to 150°C for smooth application and consistent performance.
  • Moisture & Chemical Resistance: Effectively protects against water, oils, and solvents, extending the lifespan of printed materials in humid or harsh environments.
  • UV Protection: Resists fading and yellowing caused by sunlight exposure, preserving the original appearance of printed content.
  • Eco-Friendly & Non-Toxic: Meets international safety standards, ensuring safe use in food packaging and other sensitive applications.
  • Easy Application: Compatible with both hot-melt and cold-lamination processes, ensuring efficient and cost-effective production.
Technical Specifications
  • Material: BOPP (Biaxially Oriented Polypropylene)
  • Thickness: 12μm, 15μm, 18μm, 25μm (customizable)
  • Width: 500mm – 1300mm (customizable)
  • Adhesive Type: Hot-melt or Pressure-sensitive (PSA)
  • Temperature Resistance: -20°C to +150°C
  • Moisture Resistance: <0.5%
  • Tensile Strength: ≥120MPa
  • Elongation at Break: ≥150%
  • Gloss Level: ≥80%
  • Haze: ≤1.5%
Applications
  • Printing Industry: Lamination of book covers, brochures, posters, and packaging materials to enhance durability and aesthetics.
  • Food Packaging: Used for laminating paper bags, boxes, and labels to ensure moisture resistance and food safety.
  • Office Supplies: Lamination of documents, certificates, and ID cards for protection against wear and tear.
  • Advertising: Lamination of banners, signs, and displays to improve weather resistance and longevity.
  • Industrial Use: Lamination of technical manuals, diagrams, and instructional materials for enhanced durability in harsh environments.
Advantages
  • Cost-Effective: Reduces the need for frequent replacements due to its durability.
  • Versatile: Can be used with a wide range of printing techniques and materials.
  • High-Quality Finish: Provides a professional look and feel to printed materials.
  • Eco-Friendly: Made from recyclable materials, supporting sustainability efforts.
  • Customizable: Available in various thicknesses, widths, and adhesive types to meet specific customer requirements.
Why Choose Our BOPP Thermal Lamination Film?

Our BOPP Thermal Lamination Film is manufactured using advanced technology and strict quality control measures to ensure consistent performance and reliability. We offer competitive pricing, excellent customer service, and timely delivery to meet your business needs. Whether you are a printer, packaging manufacturer, or distributor, our film is the perfect solution to enhance the quality and durability of your products.
