Name: PET Thermal Lamination Film – Engineered for Precision & Protection Technical Superiority
Brand: GUANGDONG NEW ERA COMPOSITE MATERIAL CO., LTD.
SKU: ペット
Price: 1,499.18 USD
Availability: InStock

ホーム製品ペット熱ラミネーションのフィルム

PET Thermal Lamination Film – Engineered for Precision & Protection‌ Technical Superiority‌

商品の詳細:

起源の場所:	中国広州
ブランド名:	NEi
証明:	SGS Test Report / ISO9001 / ISO14001
モデル番号:	ペット

お支払配送条件:

最小注文数量:	1つのパレット
価格:	negotiable
パッケージの詳細:	12. すべてのパレットは包装ベルトでよく詰め,ストレッチフィルムでよく包まれます.
受渡し時間:	1 つの 20GP コンテナに対して 15 -20 営業日
支払条件:	T/T、L/C、ウェスタンユニオン
供給の能力:	月額1000トン

連絡先

詳細製品概要

製品名：:	輝くPET熱ラミネーションフィルム	タイプ：:	熱ラミネーションフィルム
原産地：:	中国広州	材料：:	12 マイクロン PET + 13 マイクロン EVA
処理タイプ：:	複数の押出	透明性：:	透明
応用：:	PVC のラミネーション	紙コア::	3インチ (要求に応じて提供)
表面仕上げ：:	光沢
ハイライト:	PET thermal lamination film with warranty , precision PET lamination film , protective thermal lamination film

PET Thermal Lamination Film – Engineered for Precision & Protection

Our PET thermal lamination film is a high-performance polyester solution designed to meet the rigorous demands of professional printing and laminating applications.

Technical Superiority

Optical Clarity: ≥92% light transmission (ASTM D1003) for vibrant color reproduction
Thermal Stability: Maintains integrity at 150°C (302°F) for 30+ minutes (ASTM D4062)
Adhesion Strength: ≥4.5 N/cm (180° peel test, EVA adhesive)
Scratch Resistance: ≥3H pencil hardness (ASTM D3363)
UV Resistance: ≥500 hours QUV exposure (ASTM G154) with <5% yellowing

Material & Construction

Base Film	100% virgin PET (Polyethylene Terephthalate)
Thickness Options	25μm (standard), 50μm (heavy-duty), or custom
Adhesive Systems	EVA: Low-temperature activation (80–120°C), fast cure PUR: High-performance bond for challenging substrates
Surface Treatments	Gloss: 90°光泽度 (ASTM D523) Matte: 15°光泽度 (ASTM D523) Anti-Glare: 40°光泽度 (ASTM D523)

Performance Advantages

✅ Dimensional Stability: <0.5% shrinkage at 120°C (ASTM D1204)
✅ Chemical Resistance: Solvent-free, compatible with inks/coatings
✅ Low-Temperature Flexibility: Maintains flexibility at -20°C (-4°F)
✅ Eco-Conscious: Available in 100% recyclable PET (ISO 14001 certified)

Applications

Commercial Printing: Offset/digital prints, book covers, packaging
Industrial Labels: Barcode tags, asset ID, automotive components
Digital Graphics: Photo albums, signage, POP displays
Packaging: Luxury boxes, folding cartons, pouches

Quality Assurance

ISO 9001: Certified manufacturing process
ASTM D4302: Standard for lamination film performance
RoHS/REACH: Compliant with environmental regulations
FDA 21 CFR 177.1630: Approved for food contact applications

Customization Options

Width	12"–60" (305mm–1524mm)
Length	100m–500m per roll
Specialty Films	Anti-Static: Surface resistivity <10¹⁰ Ω/sq (IEC 61340) Textured: Embossed patterns for tactile appeal High-Barrier: O₂ transmission <5 cc/m²/day (ASTM F1249)

Why Choose Our Film?

Consistent Quality: 99.8% defect-free production (CPK ≥1.67)
Cost-Effective: Reduces material waste by 15% vs. competitive films
Global Support: Technical assistance available 24/7
Fast Lead Times: 7–10 days for standard orders

Request a Sample or Technical Data Sheet Today!

Our team is ready to assist with material selection, testing, or customization for your specific project requirements.

Note: All specifications are based on standard testing conditions. Actual performance may vary based on application parameters.
